Audi e-tron S I (2020-2024) center instrument panel control module Wiring diagram
This page shows the only wiring diagram for the component.center instrument panel control module, which is found in the car Audi e-tron S I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center instrument panel control module (1 of 1)
AUXILIARY COOLANT HEATER BUTTON
BLK/BRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER CONSOLE SWITCH MODULE 1
CENTER INSTRUMENT PANEL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
EVAPORATOR VENT TEMPERATURE SENSOR
FUSE 1
FUSE PANEL D
GRN/BLK WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INTERIOR REAR VIEW MIRROR
LEFT B-PILLAR/ FOOTWELL SHUT-OFF DOOR MOTOR
LEFT FOOTWELL VENT TEMPERATURE SENSOR
LIGHT RECOGNITION SENSOR
ORG/BRN WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT B-PILLAR/ FOOTWELL SHUT-OFF DOOR MOTOR
RIGHT FOOTWELL VENT TEMPERATURE SENSOR
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Automatic a/c circuit (3 of 6) -> CENTER INSTRUMENT PANEL CONTROL MODULE
