Audi e-tron GT I (2020-2024) Computer data lines circuit

BLK WIRE BRAKE BOOSTER BRN WIRE DIAGNOSTIC CONNECTION DIFFERENTIAL LOCKS CONTROL MODULE DRIVER DOOR CONTROL MODULE FRONT THREE-PHASE CURRENT DRIVE FUSE 12 FUSE 4 FUSE PANEL D FUSE PANEL P GRN WIRE GRN/WHT WIRE GRY/RED WIRE HIGH-VOLTAGE BATTERY CHARGER 1 HIGH-VOLTAGE BATTERY CONTROL MODULE COUPLING POINT HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT COUPLING POINT ON INSTRUMENT PANEL LEFT FRONT DOOR COUPLING POINT ORG/ WIRE ORG/BRN WIRE PNK WIRE PNK/WHT WIRE POWER OUTPUT PROTECTION W/ BOOST FUNCTION POWER STEERING CONTROL MODULE REAR AXLE STEERING CONTROL MODULE REAR THREE-PHASE CURRENT DRIVE RED WIRE RED/WHT WIRE RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT RIGHT COUPLING POINT IN LUGGAGE COMPARTMENT RIGHT END OF DASH) THERMAL MANAGEMENT CONTROL MODULE VIO WIRE YEL/BLK WIRE

AIR BAG CONTROL MODULE BLK WIRE BLU WIRE CENTER COUPLING POINT IN LUGGAGE COMPARTMENT COMFORT SYSTEM CENTRAL CONTROL MODULE FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER MEMORY SEAT CONTROL MODULE GRN WIRE GRN/WHT WIRE GRY/RED WIRE LEFT FRONT SEAT BELT LEFT FRONT SEAT COUPLING STATION MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE PNK WIRE PNK/WHT WIRE REAR LID CONTROL MODULE REAR SPOILER CONTROL MODULE RED WIRE RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT SEAT BELT RIGHT FRONT SEAT COUPLING STATION VIO WIRE W/ LANE CHANGE ASSISTANCE CONTROL MODULE W/O LANE CHANGE ASSISTANCE CONTROL MODULE

BLK WIRE BLK/VIO WIRE BLU WIRE BRN WIRE CAN BUS WIRES, RESISTANCE CENTER COUPLING POINT ON INSTRUMENT PANEL DATA BUS ON BOARD DIAGNOSTIC INTERFACE (FRONT OF CENTER CONSOLE) GRN WIRE GRN/WHT WIRE GRY WIRE INSTRUMENT CLUSTER CONTROL MODULE LEFT COUPLING POINT ON INSTRUMENT PANEL ORG/BLU WIRE ORG/BRN WIRE PNK WIRE PNK/WHT WIRE RED WIRE RED/BLU WIRE SELECTOR LEVER VIO WIRE VIO/WHT WIRE WHT WIRE WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE

ABS CONTROL MODULE (LEFT SIDE OF MOTOR COMPT) ADAPTIVE CRUISE CONTROL MODULE BATTERY BLK WIRE BLK/VIO WIRE BRN WIRE CENTER COUPLING POINT IN LUGGAGE COMPARTMENT DRIVER ASSISTANCE SYSTEMS CONTROL MODULE DRIVETRAIN CONTROL MODULE ENGINE/MOTOR CONTROL MODULE FUSE 1 FUSE 2 FUSE PANEL G FUSE PANEL H GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT LEFT COUPLING POINT IN LUGGAGE COMPARTMENT LEFT COUPLING POINT ON INSTRUMENT PANEL LEVEL CONTROL SYSTEM COMPRESSOR ELECTRONICS ORG/ WIRE ORG/BRN WIRE PNK WIRE PNK/WHT WIRE RED/BLU WIRE STEERING COLUMN ELECTRONICS CONTROL MODULE VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

BLK WIRE BOTTOM RIGHT COUPLING POINT IN INTERIOR CAN BUS WIRES, RESISTANCE CENTER COUPLING POINT IN LUGGAGE COMPARTMENT COUPLING POINT ON RIGHT FRONT BUMPER ENGINE SOUND GENERATOR CONTROL MODULE 3 GEAR ACTUATOR GRN WIRE GRN/WHT WIRE GRY WIRE HEATING, AIR CONDITIONING CONTROL MODULE LANE CHANGE ASSISTANCE CONTROL MODULE LEFT COUPLING POINT ON INSTRUMENT PANEL LEFT FRONT HEADLAMP LEFT FRONT OBJECT DETECTION RADAR SENSOR CONTROL MODULE NIGHT VISION SYSTEM CONTROL MODULE ORG/BRN WIRE ORG/WHT WIRE PNK WIRE PNK/WHT WIRE RIGHT COUPLING POINT IN LUGGAGE COMPARTMENT RIGHT FRONT HEADLAMP RIGHT FRONT OBJECT DETECTION RADAR SENSOR CONTROL MODULE TIRE PRESSURE MONITORING CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE WHT WIRE YEL WIRE

CENTER COUPLING POINT ON INSTRUMENT PANEL DATA BUS ON BOARD DIAGNOSTIC INTERFACE DRIVER VOLUME CONTROL EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE ENGINE SOUND GENERATOR CONTROL MODULE 2 FRONT INFORMATION DISPLAY CONTROL HEAD GRN WIRE GRN/WHT WIRE GRY WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 LANE CHANGE ASSISTANCE CONTROL MODULE 2 LEFT COUPLING POINT ON INSTRUMENT PANEL MOBILE DEVICE CHARGER 1 ORG/ WIRE ORG/BRN WIRE PNK WIRE PNK/WHT WIRE RADIO-CONTROLLED PARKING CONTROL MODULE REAR VIEW CAMERA SYSTEM CONTROL MODULE RIGHT COUPLING POINT ON INSTRUMENT PANEL VIO WIRE WHT WIRE
