Audi e-tron GT I (2020-2024) w/o vehicle inlet combo 2 late production Wiring diagram
This page shows the only wiring diagram for the component.w/o vehicle inlet combo 2 late production, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o vehicle inlet combo 2 late production (1 of 1)
A/C
BLK WIRE
BLU WIRE
BRN WIRE
CHARGING SOCKET TEMPERATURE SENSOR 1
DC-
EARLY PRODUCTION
FRONT PASSENGER SIDE HIGH-VOLTAGE BATTERY CHARGING SOCKET 1
FRONT THREE-PHASE CURRENT DRIVE
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/RED WIRE
HIGH-VOLTAGE BATTERY CHARGER 1 (RIGHT SIDE OF MOTOR COMPT)
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/BRN WIRE
RED WIRE
RED/GRY WIRE
W/ VEHICLE INLET COMBO 2
W/O VEHICLE INLET COMBO 2 LATE PRODUCTION
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance electric (12 of 18) -> W/O VEHICLE INLET COMBO 2 LATE PRODUCTION
