Audi e-tron GT I (2020-2024) steering coupling point 1 Wiring diagrams
This page contains all the electrical diagrams for the component. steering coupling point 1, in which he is found in the car Audi e-tron GT I (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
steering coupling point 1 wiring diagram (1 of 2)
BLK/BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 10
FUSE PANEL H
GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER CONTROL MODULE
NCA WIRE
ORG/BLU WIRE
ORG/BRN WIRE
PNK WIRE
POWER STEERING CONTROL MODULE
RED WIRE
RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
STEERING ANGLE SENSOR
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING COUPLING POINT 1
STEERING TORQUE SENSOR
WIRE JUNCTION
WIRE JUNCTION FUSE 4
Go to component -> Electromechanical power steering circuit -> STEERING COUPLING POINT 1
steering coupling point 1 wiring diagram (2 of 2)
ALARM HORN
BATTERY REGULATION CONTROL MODULE HIGH-VOLTAGE BATTERY 1
BLK/RED WIRE
BLU WIRE
CONTROL MODULE RELAY (DIAGRAM 3 OF 8)
COOLANT PUMP RELAY
ENGINE COOLANT SHUT-OFF VALVE RELAY
FROM FUSE 3 (DIAGRAM 1 OF 8)
FROM HIGH-VOLTAGE SYSTEM MAINTENANCE CONNECTOR (DIAGRAM 7 OF 8)
FRONT THREE-PHASE CURRENT DRIVE
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE 18
FUSE 19
FUSE 2
FUSE 26
FUSE 27
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
HIGH-VOLTAGE BATTERY CHARGER 1
HIGH-VOLTAGE BATTERY CONTROL MODULE COUPLING POINT
HIGH-VOLTAGE BATTERY COOLANT PUMP RELAY
LEFT COUPLING POINT IN LUGGAGE COMPARTMENT
N/A
NOT USED
POWER OUTPUT PROTECTION W/ BOOST FUNCTION
POWER STEERING CONTROL MODULE
RADIATOR FAN CONTROL RELAY
RADIATOR FAN RELAY 2
REAR AXLE STEERING CONTROL MODULE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE CARRIER 3 FUSE PANEL A
RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
STEERING COUPLING POINT 1
TO VEHICLE ELECTRICAL SYSTEM
WHT WIRE
WIRE JUNCTION
YEL WIRE
Go to component -> Power distribution circuit (2 of 8) -> STEERING COUPLING POINT 1
