Audi e-tron GT I (2020-2024) spiral spring steering column electronics control module Wiring diagram
This page shows the only wiring diagram for the component.spiral spring steering column electronics control module, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram spiral spring steering column electronics control module (1 of 1)
AIR BAG CONTROL MODULE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER AIR BAG IGNITER
DRIVER AIR BAG RELEASE VALVE IGNITER
DRIVER BELT FORCE LIMITER
DRIVER KNEE AIR BAG IGNITER
DRIVER SEAT BELT TENSIONER IGNITER 1
FRONT PASSENGER AIR BAG DEACTIVATION KEY SWITCH
FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP
FRONT PASSENGER BELT FORCE LIMITER
FRONT PASSENGER SEAT BELT TENSIONER IGNITER 1
FRONT ROOF MODULE
GRN WIRE
GRY WIRE
LEFT FRONT SEAT BELT
LEFT FRONT SEAT BELT TENSIONER CONTROL MODULE
ORG/BRN WIRE
RED WIRE
RED/YEL WIRE
RIGHT FRONT SEAT BELT
RIGHT FRONT SEAT BELT TENSIONER CONTROL MODULE
SPIRAL SPRING STEERING COLUMN ELECTRONICS CONTROL MODULE
VIO WIRE
VIO/GRY WIRE
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit (4 of 5) -> SPIRAL SPRING STEERING COLUMN ELECTRONICS CONTROL MODULE
