Audi e-tron GT I (2020-2024) relay & fuse carrier 3 fuse panel a Wiring diagram
This page shows the only wiring diagram for the component.relay & fuse carrier 3 fuse panel a, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram relay & fuse carrier 3 fuse panel a (1 of 1)
ALARM HORN
BATTERY REGULATION CONTROL MODULE HIGH-VOLTAGE BATTERY 1
BLK/RED WIRE
BLU WIRE
CONTROL MODULE RELAY (DIAGRAM 3 OF 8)
COOLANT PUMP RELAY
ENGINE COOLANT SHUT-OFF VALVE RELAY
FROM FUSE 3 (DIAGRAM 1 OF 8)
FROM HIGH-VOLTAGE SYSTEM MAINTENANCE CONNECTOR (DIAGRAM 7 OF 8)
FRONT THREE-PHASE CURRENT DRIVE
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE 18
FUSE 19
FUSE 2
FUSE 26
FUSE 27
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
HIGH-VOLTAGE BATTERY CHARGER 1
HIGH-VOLTAGE BATTERY CONTROL MODULE COUPLING POINT
HIGH-VOLTAGE BATTERY COOLANT PUMP RELAY
LEFT COUPLING POINT IN LUGGAGE COMPARTMENT
N/A
NOT USED
POWER OUTPUT PROTECTION W/ BOOST FUNCTION
POWER STEERING CONTROL MODULE
RADIATOR FAN CONTROL RELAY
RADIATOR FAN RELAY 2
REAR AXLE STEERING CONTROL MODULE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE CARRIER 3 FUSE PANEL A
RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
STEERING COUPLING POINT 1
TO VEHICLE ELECTRICAL SYSTEM
WHT WIRE
WIRE JUNCTION
YEL WIRE
Go to component -> Power distribution circuit (2 of 8) -> RELAY & FUSE CARRIER 3 FUSE PANEL A
