Audi e-tron GT I (2020-2024) rear three-phase current drive coolant temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.rear three-phase current drive coolant temperature sensor, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear three-phase current drive coolant temperature sensor (1 of 1)
BLK WIRE
BLK/GRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 6
FUSE 7
FUSE PANEL L
FUSE PANEL M
GRN WIRE
HIGH VOLTAGE BATTERY 1
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
PNK WIRE
REAR AXLE ELECTRIC DRIVE CONTROL MODULE
REAR AXLE ELECTRIC DRIVE MOTOR
REAR DRIVE MOTOR ROTOR POSITION SENSOR
REAR DRIVE MOTOR TEMPERATURE SENSOR
REAR THREE-PHASE CURRENT DRIVE
REAR THREE-PHASE CURRENT DRIVE COOLANT TEMPERATURE SENSOR
RED/YEL WIRE
RIGHT COUPLING POINT IN LUGGAGE COMPT
TRANSMISSION VEHICLE SPEED SENSOR
VIO WIRE
VIO/BLK WIRE
WHT WIRE
Go to component -> Rear axle circuit -> REAR THREE-PHASE CURRENT DRIVE COOLANT TEMPERATURE SENSOR
