Audi e-tron GT I (2020-2024) radio-controlled parking antenna 4 Wiring diagram
This page shows the only wiring diagram for the component.radio-controlled parking antenna 4, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram radio-controlled parking antenna 4 (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
COUPLING POINT ON LEFT FRONT BUMPER
COUPLING POINT ON RIGHT FRONT BUMPER
DRIVER ASSISTANCE SYSTEMS CONTROL MODULE
DRIVER ASSISTANCE SYSTEMS CONTROL MODULE (FRONT RIGHT SIDE OF CENTER CONSOLE)
FUSE 8
FUSE PANEL B
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LANE DEPARTURE WARNING CIRCUIT
LEFT FRONT CENTER PARKING AID SENSOR
LEFT FRONT PARALLEL PARKING ASSISTANCE SENSOR
LEFT FRONT PARKING AID SENSOR
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
PNK WIRE
PNK/WHT WIRE
RADIO-CONTROLLED PARKING ANTENNA 4
RADIO-CONTROLLED PARKING CONTROL MODULE
RED/BLU WIRE
RED/GRN WIRE
RIGHT FRONT CENTER PARKING AID SENSOR
RIGHT FRONT PARALLEL PARKING ASSISTANCE SENSOR
RIGHT FRONT PARKING AID SENSOR
VIO WIRE
YEL WIRE
Go to component -> Parking assistant circuit, w/ parallel parking (2 of 2) -> RADIO-CONTROLLED PARKING ANTENNA 4
