Audi e-tron GT I (2020-2024) passenger side rear sill panel strip ambient lighting lamp Wiring diagrams

BLU/YEL WIRE BRN WIRE BRN/BLK WIRE CENTER COUPLING POINT LUGGAGE COMPARTMENT COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM CONTACT SWITCH FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR LOCK UNIT FRONT PASSENGER EXTERIOR DOOR HANDLE ILLUMINATION LAMP FRONT PASSENGER SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP FUSE 8 FUSE PANEL F GRN WIRE HOT AT ALL TIMES LEFT LUGGAGE COMPARTMENT LAMP ORG/BRN WIRE PASSENGER SIDE REAR DOOR LOCK UNIT PASSENGER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP PASSENGER SIDE REAR SILL PANEL STRIP AMBIENT LIGHTING LAMP REAR LID CONTROL HEAD RED WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR COUPLING POINT RIGHT LUGGAGE COMPARTMENT LAMP RIGHT REAR DOOR COUPLING POINT VIO/BLK WIRE W/ AUXILIARY LAMPS YEL/BRN WIRE

BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CONTACT SWITCH FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR LOCK UNIT FRONT PASSENGER DOOR POWER WINDOW SWITCH FRONT PASSENGER EXTERIOR DOOR HANDLE ILLUMINATION LAMP FRONT PASSENGER INTERIOR LOCKING BUTTON FRONT PASSENGER SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP FUSE 8 FUSE PANEL F GRN WIRE HOT AT ALL TIMES LEFT FRONT DOOR COUPLING POINT ORG/BRN WIRE PASSENGER SIDE ENTRY LAMP PASSENGER SIDE INTERIOR DOOR HANDLE ILLUMINATION LAMP PASSENGER SIDE REAR DOOR CONTROL HEAD PASSENGER SIDE REAR DOOR CONTROL MODULE PASSENGER SIDE REAR DOOR LOCK UNIT PASSENGER SIDE REAR ENTRY LAMP PASSENGER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP PASSENGER SIDE REAR INTERIOR DOOR HANDLE ILLUMINATION BULB PASSENGER SIDE REAR INTERIOR LOCKING BUTTON PASSENGER SIDE REAR SILL PANEL STRIP AMBIENT LIGHTING LAMP RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT DOOR COUPLING POINT W/ AUXILIARY LAMPS YEL/BRN WIRE
