Audi e-tron GT I (2020-2024) mirror adjusting switch Wiring diagram
This page shows the only wiring diagram for the component.mirror adjusting switch, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror adjusting switch (1 of 1)
ADJUSTMENT MOTOR
ADJUSTMENT MOTOR 2
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
EXTERIOR REAR VIEW MIRROR ADJUSTER
FOLDING MOTOR
FRONT PASSENGER AUTOMATIC DIMMING EXTERIOR REAR VIEW MIRROR
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FUSE 8
FUSE PANEL F
GRN WIRE
GRY WIRE
GRY/YEL WIRE
HEATER
HORIZONTAL POSITION SENSOR
HOT AT ALL TIMES
LANE CHANGE ASSISTANCE WARNING LAMP
MIRROR ADJUSTING SWITCH
MIRROR SELECTOR SWITCH
NAVIGATION SYSTEM
ORG/BRN WIRE
PNK WIRE
RED WIRE
RIGHT FRONT DOOR COUPLING POINT
RIGHT PERIPHERAL CAMERA
TURN SIGNAL BULB
VERTICAL POSITION SENSOR
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Memory mirrors circuit (2 of 2) -> MIRROR ADJUSTING SWITCH
