Audi e-tron GT I (2020-2024) lumbar support forward/back adjustment button Wiring diagram
This page shows the only wiring diagram for the component.lumbar support forward/back adjustment button, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lumbar support forward/back adjustment button (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DRIVER BACKREST ADJUSTMENT SWITCH
DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
DRIVER SEAT ADJUSTMENT CONTROL HEAD
DRIVER SEAT ANGLE ADJUSTMENT SWITCH
DRIVER SEAT FORWARD/BACK ADJUSTMENT SWITCH
DRIVER SEAT HEIGHT ADJUSTMENT MOTOR
DRIVER SEAT HEIGHT ADJUSTMENT SWITCH
DRIVER SIDE MASSAGE FUNCTION BUTTON
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT COUPLING STATION
LUMBAR SUPPORT FORWARD/BACK ADJUSTMENT BUTTON
LUMBAR SUPPORT HEIGHT ADJUSTMENT BUTTON
MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE
ORG/BRN WIRE
RED WIRE
RELAY & FUSE CARRIER 1
SEAT DEPTH ADJUSTMENT BUTTON
VIO WIRE
VIO/GRY WIRE
VIO/RED WIRE
W/ SPORT SEATS
W/O SPORT SEATS
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Driver"s memory seat circuit, w/ sport seats & comfort seats (1 of 2) -> LUMBAR SUPPORT FORWARD/BACK ADJUSTMENT BUTTON
