Audi e-tron GT I (2020-2024) left side vent position sensor Wiring diagram
This page shows the only wiring diagram for the component.left side vent position sensor, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side vent position sensor (1 of 1)
BLK/WHT WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
FRESH AIR BLOWER
FRESH AIR BLOWER CONTROL MODULE
FUSE 3
FUSE 6
FUSE PANEL O
FUSE PANEL P
GRN/RED WIRE
HEATING, AIR CONDITIONING CONTROL MODULE
HOT AT ALL TIMES
INSTRUMENT PANEL TEMPERATURE SENSOR
LEFT CENTER VENT POSITION SENSOR
LEFT FRONT UPPER BODY VENT TEMPERATURE SENSOR
LEFT SIDE VENT POSITION SENSOR
ORG/BRN WIRE
ORG/WHT WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT CENTER VENT POSITION SENSOR
RIGHT END OF DASH)
RIGHT FRONT UPPER BODY VENT TEMPERATURE SENSOR
RIGHT SIDE VENT POSITION SENSOR
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
WHT/GRN WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Automatic a/c circuit (1 of 6) -> LEFT SIDE VENT POSITION SENSOR
