Audi e-tron GT I (2020-2024) left rear air door motor Wiring diagram
This page shows the only wiring diagram for the component.left rear air door motor, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear air door motor (1 of 1)
BLK/GRN WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
EXTERIOR AIR QUALITY, HUMIDITY SENSOR
FRONT A/C DISPLAY CONTROL HEAD
LEFT REAR AIR DISTRIBUTION MOTOR
LEFT REAR AIR DOOR MOTOR
LEFT REAR SEAT HEATING BUTTON
RED/WHT WIRE
RIGHT COUPLING POINT IN INSTRUMENT PANEL
RIGHT REAR AIR DISTRIBUTION MOTOR
RIGHT REAR AIR DOOR MOTOR
RIGHT REAR SEAT HEATING BUTTON
SEATS SYSTEM
SUNLIGHT PHOTO SENSOR
VIO WIRE
VIO/BLK WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/GRN WIRE
Go to component -> Automatic a/c circuit (2 of 6) -> LEFT REAR AIR DOOR MOTOR
