Audi e-tron GT I (2020-2024) left front reading lamp button Wiring diagrams
This page contains all the electrical diagrams for the component. left front reading lamp button, in which he is found in the car Audi e-tron GT I (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front reading lamp button (1 of 2)
BLK WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
CONTACT SWITCH
COUPLING POINT IN LEFT FRONT DOOR
DRIVER DOOR CONTROL MODULE
DRIVER DOOR LOCK UNIT
DRIVER SIDE EXTERIOR DOOR HANDLE ILLUMINATION LAMP
DRIVER SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP
EMERGENCY CALL BUTTON
FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP
FRONT ROOF MODULE (FRONT CENTER OF ROOF)
FUSE 11
FUSE PANEL C
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT READING LAMP
LEFT FRONT READING LAMP BUTTON
ORG/BRN WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT READING LAMP
RIGHT FRONT READING LAMP BUTTON
ROAD SIDE ASSISTANCE BUTTON
ROOF ELECTRONICS CONTROL MODULE
VIO/BLK WIRE
VIO/GRY WIRE
W/ AUXILIARY LAMPS
Go to component -> Courtesy lamps circuit, w/ additional lights (3 of 6) -> LEFT FRONT READING LAMP BUTTON
Wiring diagram left front reading lamp button (2 of 2)
BLK WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
CONTACT SWITCH
DRIVER DOOR CONTROL MODULE
DRIVER DOOR LOCK UNIT
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER SEAT MEMORY SETTINGS CONTROL HEAD
DRIVER SIDE ENTRY LAMP
DRIVER SIDE EXTERIOR DOOR HANDLE ILLUMINATION LAMP
DRIVER SIDE INTERIOR DOOR HANDLE ILLUMINATION LAMP
DRIVER SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP
EMERGENCY CALL BUTTON
FRONT LUGGAGE COMPARTMENT LAMP
FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP
FRONT ROOF MODULE (FRONT CENTER OF ROOF)
FUSE 11
FUSE PANEL C
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT READING LAMP
LEFT FRONT READING LAMP BUTTON
ORG/BRN WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT READING LAMP
RIGHT FRONT READING LAMP BUTTON
ROAD SIDE ASSISTANCE BUTTON
ROOF ELECTRONICS CONTROL MODULE
VIO/GRY WIRE
W/ AUXILIARY LAMPS
Go to component -> Courtesy lamps circuit, w/o additional lights (2 of 4) -> LEFT FRONT READING LAMP BUTTON
