Audi e-tron GT I (2020-2024) left front door ambient lighting bulb 1 Wiring diagram
This page shows the only wiring diagram for the component.left front door ambient lighting bulb 1, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door ambient lighting bulb 1 (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
CENTRAL LOCKING SAFE INDICATOR LAMP
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER INTERIOR LOCKING BUTTON
DRIVER SEAT MEMORY SETTINGS CONTROL HEAD
DRIVER SIDE ENTRY LAMP
DRIVER SIDE INTERIOR DOOR HANDLE ILLUMINATION LAMP
DRIVER VANITY MIRROR LAMP
DRIVER VANITY MIRROR LAMP CONTACT SWITCH
EXTERIOR REAR VIEW MIRROR ADJUSTER
FRONT PASSENGER VANITY MIRROR LAMP
FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH
FUSE 2
FUSE 5
FUSE 9
FUSE PANEL B
FUSE PANEL C
GRN/BLK WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT DOOR STORAGE COMPARTMENT ILLUMINATION LAMP
LEFT FRONT DOOR AMBIENT LIGHTING BULB 1
LEFT FRONT DOOR COUPLING POINT
LEFT REAR INTERIOR LAMP
LEFT REAR READING LAMP SWITCH
REAR LID REMOTE RELEASE BUTTON
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT REAR INTERIOR LAMP
RIGHT REAR READING LAMP SWITCH
VIO/BLK WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit, w/ additional lights (4 of 6) -> LEFT FRONT DOOR AMBIENT LIGHTING BULB 1
