Audi e-tron GT I (2020-2024) hot w/ vehicle electrical system control module relay energized Wiring diagram
This page shows the only wiring diagram for the component.hot w/ vehicle electrical system control module relay energized, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ vehicle electrical system control module relay energized (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BRN WIRE
CENTER COUPLING POINT IN LUGGAGE COMPARTMENT
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVER ASSISTANCE SYSTEMS FRONT CAMERA
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
FRONT A/C DISPLAY CONTROL HEAD
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FRONT SENSOR SYSTEM WINDOW DEFOGGER
FUSE 1
FUSE 11
FUSE 2
FUSE 8
FUSE 9
FUSE PANEL C
FUSE PANEL F
FUSE PANEL G
FUSE PANEL L
FUSE PANEL O
GRN WIRE
HEATER
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
HOT W/ VEHICLE ELECTRICAL SYSTEM CONTROL MODULE RELAY ENERGIZED
LEFT FRONT DOOR COUPLING POINT
MEMORY SYSTEMS
ORG/BRN WIRE
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER BUTTON
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE CARRIER 1
RELAY & FUSE CARRIER 4 REAR WINDOW DEFOGGER RELAY
RIGHT FRONT DOOR COUPLING POINT
SUPPRESSION FILTER
VIO WIRE
VIO/YEL WIRE
WINDSHIELD ANTENNA SUPPRESSION FILTER
Go to component -> Defoggers circuit -> HOT W/ VEHICLE ELECTRICAL SYSTEM CONTROL MODULE RELAY ENERGIZED
