Audi e-tron GT I (2020-2024) headlamp switch illumination lamp Wiring diagrams
This page contains all the electrical diagrams for the component. headlamp switch illumination lamp, in which he is found in the car Audi e-tron GT I (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
headlamp switch illumination lamp wiring diagram (1 of 3)
BRN WIRE
COMPUTER DATA LINES SYSTEM
FOG LAMP BUTTON
FUSE 12
FUSE 2
FUSE 5
FUSE PANEL B
FUSE PANEL O
GRN WIRE
GRY WIRE
HEADLAMP SWITCH ILLUMINATION LAMP
HOT AT ALL TIMES
LEFT COUPLING POINT ON INSTRUMENT PANEL
LIGHT SWITCH
ORG/BRN WIRE
PNK WIRE
REAR FOG LAMP BUTTON
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
RIGHT FRONT HEADLAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT LED HEADLAMP POWER OUTPUT MODULE 1
RIGHT STATIONARY CORNERING LAMP
STEERING COLUMN ELECTRONICS CONTROL MODULE
TURN SIGNAL SWITCH
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/YEL WIRE
W/ LENS
W/O LENS
Go to component -> Exterior lamps circuit (3 of 3) -> HEADLAMP SWITCH ILLUMINATION LAMP
headlamp switch illumination lamp wiring diagram (2 of 3)
BRN WIRE
CENTER COUPLING POINT ON ROOF
COMPUTER DATA LINES SYSTEM
FOG LAMP BUTTON
FUSE 2
FUSE 5
FUSE 7
FUSE PANEL B
FUSE PANEL O
GRN WIRE
HEADLAMP SWITCH ILLUMINATION LAMP
HOT AT ALL TIMES
HUMIDITY SENSOR
LEFT AUXILIARY HIGH BEAM LAMP
LEFT COUPLING POINT ON INSTRUMENT PANEL
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT HEADLAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP FAN
LEFT HEADLAMP RANGE CONTROL ADJUSTMENT MOTOR
LEFT HIGH BEAM HEADLAMP LAMP
LEFT LED HEADLAMP POWER OUTPUT MODULE 1
LEFT LOW BEAM HEADLAMP LAMP
LEFT STATIONARY CORNERING LAMP
LIGHT SWITCH
ORG/BRN WIRE
RAIN/LIGHT RECOGNITION SENSOR
REAR FOG LAMP BUTTON
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
VIO/YEL WIRE
YEL WIRE
Go to component -> Headlights circuit, w/ lens (1 of 2) -> HEADLAMP SWITCH ILLUMINATION LAMP
headlamp switch illumination lamp wiring diagram (3 of 3)
