Audi e-tron GT I (2020-2024) front luggage compartment emergency release actuator Wiring diagram
This page shows the only wiring diagram for the component.front luggage compartment emergency release actuator, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front luggage compartment emergency release actuator (1 of 1)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
COUPLING POINT ON RIGHT FRONT BUMPER
FRONT LUGGAGE COMPARTMENT EMERGENCY RELEASE ACTUATOR
FUSE 9
FUSE PANEL K
GRN WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
LEFT COOLING AIR DOOR POSITION SENSOR
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
ORG/BRN WIRE
REAR SPOILER CONTROL MODULE
REAR SPOILER MOTOR
REAR SPOILER POSITION SENSOR REAR SPOILER ADJUSTMENT DRIVE UNIT
REAR SPOILER STOP SWITCH 1
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT COOLING AIR DOOR POSITION SENSOR
YEL WIRE
Go to component -> Active rear spoiler circuit -> FRONT LUGGAGE COMPARTMENT EMERGENCY RELEASE ACTUATOR
