Audi e-tron GT I (2020-2024) engine sound generator actuator 4 Wiring diagram
This page shows the only wiring diagram for the component.engine sound generator actuator 4, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine sound generator actuator 4 (1 of 1)
BLK/BLU WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BRN WIRE
BRN/RED WIRE
CENTER COUPLING POINT IN LUGGAGE COMPARTMENT
COMPUTER DATA LINES SYSTEM
COUPLING POINT IN LEFT REAR DOOR
COUPLING POINT IN RIGHT REAR DOOR
ENGINE SOUND GENERATOR ACTUATOR 3
ENGINE SOUND GENERATOR ACTUATOR 4
ENGINE SOUND GENERATOR CONTROL MODULE 2
ENGINE SOUND GENERATOR CONTROL MODULE 3 (RIGHT SIDE OF LUGGAGE COMPT)
FUSE 11
FUSE 9
FUSE PANEL M
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
LEFT REAR DOOR COUPLING POINT
LEFT REAR MIDRANGE SPEAKER W/ AUXILIARY INTERIOR SPEAKER
ORG/BRN WIRE
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR MIDRANGE SPEAKER W/ AUXILIARY INTERIOR SPEAKER
WHT/VIO WIRE
Go to component -> Virtual engine sound system circuit -> ENGINE SOUND GENERATOR ACTUATOR 4
