Audi e-tron GT I (2020-2024) driver side rear power window button Wiring diagram
This page shows the only wiring diagram for the component.driver side rear power window button, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side rear power window button (1 of 1)
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CHILD SAFETY LOCK BUTTON
CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER POWER WINDOW BUTTON
DRIVER SIDE REAR DOOR CONTROL HEAD
DRIVER SIDE REAR DOOR CONTROL MODULE
DRIVER SIDE REAR POWER WINDOW BUTTON
DRIVER WINDOW REGULATOR MOTOR
FRONT PASSENGER POWER WINDOW BUTTON
FUSE 11
FUSE 2
FUSE PANEL C (LEFT KICK PANEL)
GRN WIRE
GRN/YEL WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT CHILD SAFETY LOCK BUTTON
LEFT CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP
LEFT FRONT DOOR COUPLING POINT
LEFT REAR DOOR COUPLING POINT
ORG/BRN WIRE
PASSENGER SIDE REAR POWER WINDOW BUTTON
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT CHILD SAFETY LOCK BUTTON
RIGHT CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP
VIO/WHT WIRE
WHT/YEL WIRE
YEL WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Power windows circuit (1 of 2) -> DRIVER SIDE REAR POWER WINDOW BUTTON
