Audi e-tron GT I (2020-2024) driver interior locking indicator lamp Wiring diagram
This page shows the only wiring diagram for the component.driver interior locking indicator lamp, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver interior locking indicator lamp (1 of 1)
ACCESS/START AUTHORIZATION BUTTON
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
COURTESY LAMPS CIRCUIT
DRIVER DOOR CONTROL MODULE
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER INTERIOR LOCKING BUTTON
DRIVER INTERIOR LOCKING INDICATOR LAMP
DRIVER SEAT MEMORY SETTINGS CONTROL HEAD
EXTERIOR REAR VIEW MIRROR ADJUSTER
FOG LAMP BUTTON
FOG LAMP INDICATOR LAMP
FUSE 11
FUSE 2
FUSE 5
FUSE PANEL B
FUSE PANEL C
FUSE PANEL O
GRN WIRE
GRY/RED WIRE
HEADLAMP SWITCH ILLUMINATION BULB
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LEFT COUPLING POINT ON INSTRUMENT PANEL
LEFT FRONT DOOR COUPLING POINT
LIGHT SWITCH
ORG/BRN WIRE
POSITION LAMP INDICATOR LAMP
REAR FOG LAMP BUTTON
REAR FOG LAMP INDICATOR LAMP
REAR LID REMOTE RELEASE BUTTON
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/WHT WIRE
USB CHARGING SOCKET 2
USB CONNECTION 1
USB DISTRIBUTOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/YEL WIRE
WHT/GRY WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> DRIVER INTERIOR LOCKING INDICATOR LAMP
