Audi e-tron GT I (2020-2024) drive motor rotor position sensor 1 Wiring diagram
This page shows the only wiring diagram for the component.drive motor rotor position sensor 1, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drive motor rotor position sensor 1 (1 of 1)
BLK WIRE
BLK/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVE MOTOR ROTOR POSITION SENSOR 1
FRONT AXLE ELECTRIC DRIVE CONTROL MODULE
FRONT AXLE ELECTRIC DRIVE MOTOR
FRONT DRIVE MOTOR TEMPERATURE SENSOR
FRONT THREE-PHASE CURRENT DRIVE
FRONT THREE-PHASE CURRENT DRIVE COOLANT TEMPERATURE SENSOR
FUSE 5
FUSE PANEL A
FUSE PANEL H
GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
PNK WIRE
POWER OUTPUT PROTECTION W/ BOOST FUNCTION
RED WIRE
RIGHT COUPLING POINT IN ENGINE/ MOTOR COMPARTMENT
WHT WIRE
Go to component -> Front axle circuit -> DRIVE MOTOR ROTOR POSITION SENSOR 1
