Audi e-tron GT I (2020-2024) dimming exterior rear view mirror Wiring diagram
This page shows the only wiring diagram for the component.dimming exterior rear view mirror, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dimming exterior rear view mirror (1 of 1)
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BRN WIRE
CENTER COUPLING POINT ON ROOF
COMPUTER DATA LINES SYSTEM
DIMMING EXTERIOR REAR VIEW MIRROR
DRIVER AUTOMATIC DIMMING EXTERIOR REAR VIEW MIRROR
DRIVER DOOR CONTROL MODULE
FRONT PASSENGER AUTOMATIC DIMMING EXTERIOR REAR VIEW MIRROR
FRONT PASSENGER DOOR CONTROL MODULE
FUSE 11
FUSE 8
FUSE PANEL C
FUSE PANEL D
FUSE PANEL F
GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INTERIOR REAR VIEW MIRROR
LEFT FRONT DOOR COUPLING POINT
LIGHT RECOGNITION SENSOR
ORG/BRN WIRE
RED WIRE
RIGHT FRONT DOOR COUPLING POINT
VIO/GRY WIRE
Go to component -> Power mirrors circuit -> DIMMING EXTERIOR REAR VIEW MIRROR
