Audi e-tron GT I (2020-2024) coupling point in right front door Wiring diagrams

BLK/RED WIRE BLK/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE COUPLING POINT IN LEFT FRONT DOOR COUPLING POINT IN RIGHT FRONT DOOR DIGITAL SOUND SYSTEM CONTROL MODULE DIGITAL SOUND SYSTEM FUSE DUAL SUBWOOFER SPEAKER 1 DUAL SUBWOOFER SPEAKER 2 EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE GRN WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT EFFECTS SPEAKER LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT MIDRANGE SPEAKER PNK WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RELAY & FUSE CARRIER 1 RIGHT EFFECTS SPEAKER RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT MIDRANGE SPEAKER SUBWOOFER VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE

ANTENNA ANTENNA AMPLIFIER BLK WIRE BLK/BLU WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COUPLING POINT IN LEFT FRONT DOOR COUPLING POINT IN RIGHT FRONT DOOR COUPLING POINT ON RIGHT C-PILLAR FUSE 2 FUSE PANEL P GRN WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT COUPLING POINT ON INSTRUMENT PANEL LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER NCA WIRE RADIO ANTENNA 2 ANTENNA AMPLIFIER 2 RED WIRE RED/BLU WIRE RED/GRN WIRE RIGHT COUPLING POINT ON INSTRUMENT CLUSTER RIGHT COUPLING POINT ON INSTRUMENT PANEL RIGHT END OF DASH) RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER SATELLITE TUNER ANTENNA (W/ DIGITAL RADIO) (CENTER OF REAR LID) WHT WIRE WHT/BLU WIRE WHT/GRN WIRE

BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT IN LEFT FRONT DOOR COUPLING POINT IN RIGHT FRONT DOOR COUPLING POINT ON LEFT FRONT BUMPER DRIVER ASSISTANCE SYSTEMS CONTROL MODULE DRIVER EXTERIOR REAR VIEW MIRROR FRONT PASSENGER EXTERIOR REAR VIEW MIRROR FRONT PERIPHERAL CAMERA FUSE 7 FUSE PANEL F GRN WIRE HOT AT ALL TIMES LEFT FRONT DOOR COUPLING POINT LEFT PERIPHERAL CAMERA NCA WIRE PNK WIRE REAR PERIPHERAL CAMERA RED/BLU WIRE RIGHT FRONT DOOR COUPLING POINT RIGHT PERIPHERAL CAMERA

BLK/RED WIRE BLK/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE COUPLING POINT IN LEFT FRONT DOOR COUPLING POINT IN RIGHT FRONT DOOR DIGITAL SOUND SYSTEM CONTROL MODULE DIGITAL SOUND SYSTEM FUSE DUAL SUBWOOFER SPEAKER 1 DUAL SUBWOOFER SPEAKER 2 EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE GRN WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT EFFECTS SPEAKER LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT MIDRANGE SPEAKER PNK WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RELAY & FUSE CARRIER 1 RIGHT EFFECTS SPEAKER RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT MIDRANGE SPEAKER SUBWOOFER VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE

ANTENNA ANTENNA AMPLIFIER BLK WIRE BLK/BLU WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COUPLING POINT IN LEFT FRONT DOOR COUPLING POINT IN RIGHT FRONT DOOR COUPLING POINT ON RIGHT C-PILLAR FUSE 2 FUSE PANEL P GRN WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT COUPLING POINT ON INSTRUMENT PANEL LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER NCA WIRE RADIO ANTENNA 2 ANTENNA AMPLIFIER 2 RED WIRE RED/BLU WIRE RED/GRN WIRE RIGHT COUPLING POINT ON INSTRUMENT CLUSTER RIGHT COUPLING POINT ON INSTRUMENT PANEL RIGHT END OF DASH) RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER SATELLITE TUNER ANTENNA (W/ DIGITAL RADIO) (CENTER OF REAR LID) WHT WIRE WHT/BLU WIRE WHT/GRN WIRE
