Audi e-tron GT I (2020-2024) coolant temperature sensor before heat exchanger Wiring diagram
This page shows the only wiring diagram for the component.coolant temperature sensor before heat exchanger, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coolant temperature sensor before heat exchanger (1 of 1)
A/C PRESSURE TEMPERATURE SENSOR 2
A/C PRESSURE/ TEMPERATURE SENSOR
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE SENSOR BEFORE HEAT EXCHANGER
ENGINE CONTROLS SYSTEM
ENGINE COOLANT LEVEL SENSOR 2
EVAPORATOR TEMPERATURE SENSOR
FUSE 20
FUSE PANEL A
GRN WIRE
GRN/WHT WIRE
HEATING, AIR CONDITIONING CONTROL MODULE
HOT AT ALL TIMES
LEFT FOOTWELL VENT TEMPERATURE SENSOR
ORG/ WIRE
ORG/BRN WIRE
OUTSIDE AIR TEMPERATURE SENSOR
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RELAY & FUSE PANEL 3
RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
RIGHT FOOTWELL VENT TEMPERATURE SENSOR
THERMAL MANAGEMENT CONTROL MODULE
VIO/BLU WIRE
VIO/GRY WIRE
VIO/WHT WIRE
YEL/BLU WIRE
Go to component -> Automatic a/c circuit (6 of 6) -> COOLANT TEMPERATURE SENSOR BEFORE HEAT EXCHANGER
