Audi e-tron GT I (2020-2024) center windshield emergency call module antenna 3 Wiring diagram
This page shows the only wiring diagram for the component.center windshield emergency call module antenna 3, which is found in the car Audi e-tron GT I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center windshield emergency call module antenna 3 (1 of 1)
BLK WIRE
BLK/YEL WIRE
CENTER WINDSHIELD EMERGENCY CALL MODULE ANTENNA 3
COUPLING POINT ON LEFT FRONT BUMPER
EMERGENCY CALL MODULE ANTENNA 4
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FUSE 9
FUSE PANEL D
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LEFT EMERGENCY CALL MODULE ANTENNA
LEFT EMERGENCY CALL MODULE ANTENNA 2
NCA WIRE
RIGHT COUPLING POINT ON INSTRUMENT PANEL
RIGHT WIRELESS DATA TRANSFER ANTENNA 2
WIRELESS DATA TRANSFER ANTENNA
Go to component -> Emergency call circuit (2 of 2) -> CENTER WINDSHIELD EMERGENCY CALL MODULE ANTENNA 3
