Exterior lamps circuit for Audi Cabriolet I (1991-2000)

BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BRAKE LIGHT SWITCH BRN WIRE EMERGENCY FLASHER RELAY EMERGENCY FLASHER SWITCH FUSE FUSE 2 FUSE/ RELAY PANEL GRN WIRE GRN/RED WIRE GRY WIRE GRY/GRN WIRE HEAD HEADLIGHT DIMMER/ FLASHER SWITCH HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES HOT IN INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LEFT FRONT PARK/ TURN LIGHT LEFT REAR SIDE MARKER/ TAIL/STOP/ TURN LIGHTS LEFT TURN IND LICENSE PLATE LIGHTS LOAD REDUCTION RELAY MKR TAIL STOP OFF HEAD PARK OFF PARK PARK TURN RED WIRE RIGHT FRONT PARK/ TURN LIGHT RIGHT REAR SIDE MARKER/ TAIL/STOP/ TURN LIGHTS RIGHT TURN IND RUN WIRE SOLID STATE TURN TURN PARK TURN SIGNAL SWITCH WHT WIRE YEL WIRE
