Audi Cabriolet I (1991-2000) trunk compt light Wiring diagram
This page shows the only wiring diagram for the component.trunk compt light, which is found in the car Audi Cabriolet I (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk compt light (1 of 1)
ANTENNA
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/WHT WIRE
CONVERTIBLE TOP CONTROL
DATA LINK CONN (NEAR RELAY PANEL) DATA LINK CONN (NEAR REAR ASHTRAY LIGHT)
DRIVER DOOR CENTRAL LOCKING SYSTEM SWITCH
DRIVER DOOR HANDLE ALARM SWITCH
FUSE
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
HOOD ALARM SWITCH
HOT AT ALL TIMES
IGNITION SWITCH
KEY SWITCH
MODULE
NCA WIRE
OFF ON
PARK/ NEUTRAL POSITION RELAY (FRONT AUXILIARY RELAY PANEL, POSITION NO 1)
PASSENGER DOOR CENTRAL LOCKING SYSTEM SWITCH
PASSENGER DOOR HANDLE ALARM SWITCH
RADIO
REAR FOG LIGHT SWITCH
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RIGHT FRONT DOOR CONTACT SWITCH LEFT FRONT DOOR CONTACT SWITCH
STARTER
TRUNK COMPT LIGHT
TRUNK COMPT LIGHT SWITCH
TRUNK LID ALARM SWITCH
TRUNK LOCK ALARM/ CENTRAL LOCKING SWITCH
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
Go to component: -> Anti-theft circuit -> TRUNK COMPT LIGHT
