Audi Cabriolet I (1991-2000) tensioning bow position switch Wiring diagram
This page shows the only wiring diagram for the component.tensioning bow position switch, which is found in the car Audi Cabriolet I (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tensioning bow position switch (1 of 1)
A/3
A/9
ACTIVE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/WHT WIRE
BRN/YEL WIRE
C/10 A/11
CENTRAL LOCKING/ ALARM SYSTEM/ INTERIOR LIGHT DELAY CONTROL MODULE
COMPARTMENT COVER OPEN POSITION SWITCH
CONVERTIBLE TOP HYDRAULIC PUMP
CONVERTIBLE TOP HYDRAULIC PUMP RELAY
CONVERTIBLE TOP HYDRAULIC PUMP/ SOLENOID VALVE ASSEMBLY
CONVERTIBLE TOP SWITCH
DECKLID CENTRAL LOCKING SYSTEM MOTOR
DRIVER DOOR CENTRAL LOCKING SYSTEM SWITCH
FRONT AUXILIARY
FUSE 19
FUSE 24
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT WITH LOAD REDUCTION RELAY ENERGIZED
MAIN FUSE/ RELAY PANEL
NCA WIRE
PASSENGER DOOR CENTRAL LOCKING SYSTEM SWITCH
RED WIRE
RELAY PANEL (BEHIND LEFT SIDE OF DASH)
SOLENOID VALVE 1
SOLENOID VALVE 2
SOLENOID VALVE 3
SOLENOID VALVE 4
SOLENOID VALVE 5
SOLENOID VALVE 6
STOWED RAISED
TENSIONING BOW POSITION SWITCH
TRUNK LID ALARM SWITCH
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Power top/sunroof circuit (2 of 2) -> TENSIONING BOW POSITION SWITCH
