Audi Cabriolet I (1991-2000) passenger's seat backrest locking warning buzzer Wiring diagram

This page shows the only wiring diagram for the component.passenger's seat backrest locking warning buzzer, which is found in the car Audi Cabriolet I (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram passenger's seat backrest locking warning buzzer (1 of 1)

Wiring diagram passenger's seat backrest locking warning buzzer for Audi Cabriolet I (1991-2000)

Get access

ADJUSTING SWITCH AUXILIARY RELAY PANEL BLK WIRE BLK/BLU WIRE BLU WIRE BRN WIRE CIRCUIT BREAKER 44 CIRCUIT BREAKER 80 DRIVER'S SEAT BACKREST LOCKING ADJUSTING SWITCH DRIVER'S SEAT BACKREST LOCKING WARNING BUZZER DRIVER'S SEAT FRONT HEIGHT ADJUSTING MOTOR DRIVER'S SEAT FRONT HEIGHT ADJUSTING SWITCH FUSE PANEL GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC PASSENGER'S SEAT BACKREST LOCKING PASSENGER'S SEAT BACKREST LOCKING WARNING BUZZER PASSENGER'S SEAT FRONT HEIGHT ADJUSTING MOTOR PASSENGER'S SEAT FRONT HEIGHT ADJUSTING SWITCH RED WIRE

Go to component: -> Power seats circuit -> PASSENGER'S SEAT BACKREST LOCKING WARNING BUZZER
