Audi Cabriolet I (1991-2000) off head park Wiring diagrams
This page contains all the electrical diagrams for the component. off head park, in which he is found in the car Audi Cabriolet I (1991-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram off head park (1 of 2)
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE LIGHT SWITCH
BRN WIRE
EMERGENCY FLASHER RELAY
EMERGENCY FLASHER SWITCH
FUSE
FUSE 2
FUSE/ RELAY PANEL
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/GRN WIRE
HEAD
HEADLIGHT DIMMER/ FLASHER SWITCH
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
HOT IN
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT PARK/ TURN LIGHT
LEFT REAR SIDE MARKER/ TAIL/STOP/ TURN LIGHTS
LEFT TURN IND
LICENSE PLATE LIGHTS
LOAD REDUCTION RELAY
MKR TAIL STOP
OFF HEAD PARK
OFF PARK
PARK TURN
RED WIRE
RIGHT FRONT PARK/ TURN LIGHT
RIGHT REAR SIDE MARKER/ TAIL/STOP/ TURN LIGHTS
RIGHT TURN IND
RUN WIRE
SOLID STATE
TURN
TURN PARK
TURN SIGNAL SWITCH
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> OFF HEAD PARK
Wiring diagram off head park (2 of 2)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
FOG LIGHT RELAY
FOG LIGHT SWITCH
FTP
FUSE
FUSE/ RELAY
FUSE/ RELAY PANEL
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HEAD
HEADLIGHT DIMMER SWITCH
HI FTP LO
HI LO
HOT AT ALL TIMES
IGNITION SWITCH
IND
INSTRUMENT CLUSTER HI BEAM
LEFT FRONT FOG LIGHT RIGHT FRONT FOG LIGHT
LEFT HEAD- LIGHT
LIGHT SWITCH
LOAD REDUCTION RELAY
OFF
OFF HEAD PARK
PANEL)
REAR FOG LIGHT
REAR FOG LIGHT SWITCH
RIGHT HEAD- LIGHT
RUN WIRE
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Headlamps & fog lamps circuit -> OFF HEAD PARK
