Audi Cabriolet I (1991-2000) mkr tail stop Wiring diagram
This page shows the only wiring diagram for the component.mkr tail stop, which is found in the car Audi Cabriolet I (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mkr tail stop (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE LIGHT SWITCH
BRN WIRE
EMERGENCY FLASHER RELAY
EMERGENCY FLASHER SWITCH
FUSE
FUSE 2
FUSE/ RELAY PANEL
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/GRN WIRE
HEAD
HEADLIGHT DIMMER/ FLASHER SWITCH
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
HOT IN
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT PARK/ TURN LIGHT
LEFT REAR SIDE MARKER/ TAIL/STOP/ TURN LIGHTS
LEFT TURN IND
LICENSE PLATE LIGHTS
LOAD REDUCTION RELAY
MKR TAIL STOP
OFF HEAD PARK
OFF PARK
PARK TURN
RED WIRE
RIGHT FRONT PARK/ TURN LIGHT
RIGHT REAR SIDE MARKER/ TAIL/STOP/ TURN LIGHTS
RIGHT TURN IND
RUN WIRE
SOLID STATE
TURN
TURN PARK
TURN SIGNAL SWITCH
WHT WIRE
YEL WIRE
Go to component: -> Exterior lamps circuit -> MKR TAIL STOP
