Audi Cabriolet I (1991-2000) left headlight Wiring diagram
This page shows the only wiring diagram for the component.left headlight, which is found in the car Audi Cabriolet I (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left headlight (1 of 1)
ABS HYDRAULIC UNIT
AUXILIARY RELAY PANEL (LEFT SIDE OF ENG COMPT) FUSE 42
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CENTRAL REAR ASHTRAY LIGHT
CIRCUIT BREAKER 44
CIRCUIT BREAKER 64
CIRCUIT BREAKER 80
CONVERTIBLE TOP CONTROL MODULE
CONVERTIBLE TOP HYDRAULIC PUMP
COOLANT FAN CONTROL RELAY
DRIVER SEAT FRONT HEIGHT ADJUSTING SWITCH
ENGINE COOLANT TEMPERATURE ELECTRONIC THERMOSWITCH
FOG LIGHT RELAY
FROM FUSE/ RELAY PANEL (DIAGRAM 1 OF 2)
FUSE 10
FUSE 11 FUSE 10
FUSE 12
FUSE 16
FUSE 17
FUSE 18
FUSE 19
FUSE 24
FUSE 43
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
GRY WIRE
HEADLIGHT DIMMER/ FLASHER SWITCH
HEATED DOOR LOCK SWITCHES, CENTRAL LOCKING/
INSTRUMENT CLUSTER (HIGH BEAM RELAY)
LEFT HEADLIGHT
LEFT HEADLIGHT RIGHT HEADLIGHT
LICENSE PLATE LIGHT GLOVE COMPARTMENT LIGHT, INSTRUMENT CLUSTER
LIGHT SWITCH
MAIN FUSE/ RELAY PANEL (BEHIND LEFT SIDE OF DASH)
MIRROR ADJUSTMENT SWITCH
PASSENGER SEAT FRONT HEIGHT ADJUSTING SWITCH
POWER WINDOW CONTROL MODULE, POWER WINDOW OPENING, CLOSING RELAYS
POWER WINDOW OPENING, CLOSING RELAYS
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RIGHT HEADLIGHT
RIGHT PARKING LIGHT LEFT TAIL LIGHT
RIGHT TAIL LIGHT RIGHT PARKING LIGHT
SECOND AND THIRD SPEED COOLANT FAN CONTROL RELAYS
WHT WIRE
YEL WIRE
Go to component: -> Power distribution circuit (2 of 2) -> LEFT HEADLIGHT
