Audi Cabriolet I (1991-2000) left head- light Wiring diagram

This page shows the only wiring diagram for the component.left head- light, which is found in the car Audi Cabriolet I (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left head- light (1 of 1)

Wiring diagram left head- light for Audi Cabriolet I (1991-2000)

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE FOG LIGHT RELAY FOG LIGHT SWITCH FTP FUSE FUSE/ RELAY FUSE/ RELAY PANEL GRN WIRE GRY WIRE GRY/BLU WIRE GRY/GRN WIRE HEAD HEADLIGHT DIMMER SWITCH HI FTP LO HI LO HOT AT ALL TIMES IGNITION SWITCH IND INSTRUMENT CLUSTER HI BEAM LEFT FRONT FOG LIGHT RIGHT FRONT FOG LIGHT LEFT HEAD- LIGHT LIGHT SWITCH LOAD REDUCTION RELAY OFF OFF HEAD PARK PANEL) REAR FOG LIGHT REAR FOG LIGHT SWITCH RIGHT HEAD- LIGHT RUN WIRE WHT WIRE WHT/YEL WIRE YEL WIRE

Go to component: -> Headlamps & fog lamps circuit -> LEFT HEAD- LIGHT
