Audi Cabriolet I (1991-2000) gry/wht Wiring diagram
This page shows the only wiring diagram for the component.gry/wht, which is found in the car Audi Cabriolet I (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gry/wht (1 of 1)
AMPLIFIER
ANTENNA AMPLIFIER
BLK/GRN WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BRN WIRE
BRN/RED WIRE
CD CHANGER UNIT
FUSE 4
FUSE/ RELAY PANEL
GRN WIRE
GRY/BLU WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT SPEAKER
LEFT REAR WOOFER
LOCK
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
RADIO
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT SPEAKER
RIGHT REAR WOOFER
RUN WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
Go to component: -> Radio circuit -> GRY/WHT WIRE
