Audi Cabriolet I (1991-2000) coolant fan control thermo switch Wiring diagram

This page shows the only wiring diagram for the component.coolant fan control thermo switch, which is found in the car Audi Cabriolet I (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram coolant fan control thermo switch (1 of 1)

Wiring diagram coolant fan control thermo switch for Audi Cabriolet I (1991-2000)

Get access

A/C REFRIGERANT HIGH PRESSURE SWITCH A/C SWITCH AUXILIARY AUXILIARY RELAY PANEL (BEHIND LEFT SIDE OF DASH) BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE COOLANT FAN CONTROL RELAY COOLANT FAN CONTROL SERIES RESISTANCE COOLANT FAN CONTROL THERMO SWITCH COOLANT FAN FUSE 42 COOLANT FANS FRESH AIR BLOWER SWITCH FUSE 15 FUSE/ RELAY PANEL (LEFT SIDE PLENUM TRAY) GRN WIRE HEATER FAN RELAY HOT AT ALL TIMES HOT W/LOAD REDUCTION RELAY ENERGIZED RED WIRE RED/BLK WIRE RED/WHT WIRE RELAY PANEL SECOND SPEED COOLANT FAN CONTROL RELAY THIRD SPEED COOLANT FAN CONTROL RELAY WHT WIRE YEL WIRE

Go to component: -> Cooling fan circuit -> COOLANT FAN CONTROL THERMO SWITCH
