Audi Cabriolet I (1991-2000) a/c refrig- erant low pressure switch wiring diagram
This page shows the only wiring diagram for the component.a/c refrig- erant low pressure switch, which is found in the car Audi Cabriolet I (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
a/c refrig- erant low pressure switch wiring diagram (1 of 1)
1995 VFTC
A/C CLUTCH CONTROL MODULE (ON FRONT AUX RELAY PANEL)
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR SPEED SENSOR
A/C FLAP SOLENOID
A/C REFRIG- ERANT LOW PRESSURE SWITCH
A/C REFRIGERANT HIGH PRESSURE SWITCH
A/C SWITCH
AMBIENT TEMPER- ATURE SWITCH (RIGHT REAR OF ENG COMPT)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLOWER MOTOR
BLOWER RESISTORS
BLOWER SWITCH
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COOLANT FAN
COOLANT FAN CONTROL RELAY
COOLANT FAN CONTROL SERIES RESISTORS (LEFT FRONT CONRNER OF ENGINE COMPT)
COOLANT FAN CONTROL THERMOSWITCH
DATA LINK CONNECTOR
ENGINE CONTROL MODULE (RIGHT SIDE OF DASH)
ENGINE COOLANT TEMPERATURE ELECTRONIC THERMO SWITCH (TOP REAR CORNER OF ENGINE)
ENGINE COOLANT TEMPERATURE GAUGE
FUSE 12
FUSE 15
FUSE 17
FUSE 42
FUSE/ RELAY PANEL
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HEATER FAN RELAY
HOT AT ALL TIMES AUXILIARY RELAY PANEL
HOT WITH LOAD REDUCTION RELAY ENERGIZED (X)
IGNITION (15)
OFF
PROTECTION DIODE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
SECOND SPEED COOLANT FAN CONTROL RELAY
THIRD SPEED COOLANT FAN CONTROL RELAY
TRANSMISSION CONTROL MODULE (NOT USED) (NOT USED)
WIRE DISTRIBUTOR
Go to component -> Manual a/c circuit -> A/C REFRIG- ERANT LOW PRESSURE SWITCH
