Parking assistant circuit, w/ parallel parking & w/o driver assistance for Audi A8 D5 facelift (2021-2024)

BLK/YEL WIRE BLU WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON LEFT FRONT BUMPER FRONT PARKING AID WARNING BUZZER FUSE 2 FUSE PANEL D GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT FRONT CENTER PARKING AID SENSOR LEFT FRONT PARALLEL PARKING ASSISTANCE SENSOR LEFT FRONT PARKING AID SENSOR ORG/BRN WIRE RED/BLU WIRE RIGHT FRONT CENTER PARKING AID SENSOR RIGHT FRONT PARALLEL PARKING ASSISTANCE SENSOR RIGHT FRONT PARKING AID SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLU WIRE VIO/GRN WIRE VIO/YEL WIRE WHT/GRN WIRE WHT/GRY WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/RED WIRE

BLK/YEL WIRE BRN/GRN WIRE BRN/WHT WIRE CENTER CONSOLE SWITCH MODULE 1 COMPUTER DATA LINES SYSTEM COUPLING POINT ON LEFT REAR BUMPER FUSE 11 FUSE PANEL F GRN/BLK WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT REAR CENTER PARKING AID SENSOR LEFT REAR PARALLEL PARKING ASSISTANCE SENSOR LEFT REAR PARKING AID SENSOR PARALLEL PARKING ASSISTANCE BUTTON PARALLEL PARKING ASSISTANCE INDICATOR LAMP PARKING AID BUTTON PARKING AID INDICATOR LAMP RIGHT REAR CENTER PARKING AID SENSOR RIGHT REAR PARALLEL PARKING ASSISTANCE SENSOR RIGHT REAR PARKING AID SENSOR VIO/BLU WIRE VIO/WHT WIRE WHT/GRN WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/RED WIRE
