Rear heated seats circuit, w/ standard seats & central control unit for Audi A8 D5 (2017-2022)

AUXILIARY DISPLAY CONTROL HEAD 1 BLK WIRE BLU WIRE BLU/RED WIRE BLU/VIO WIRE BRN WIRE CENTER REAR SEAT COUPLING STATION COMPUTER DATA LINES SYSTEM FUSE 1 FUSE 11 FUSE 7 FUSE 8 FUSE PANEL H FUSE PANEL P GRN WIRE GRY/RED WIRE GRY/VIO WIRE HEATING ELEMENT CONTROL MODULE 1 HEATING ELEMENT CONTROL MODULE 2 HOT AT ALL TIMES LEFT REAR CENTER ARMREST HEATING ELEMENT LEFT REAR SEAT COUPLING STATION N/A ORG/BRN WIRE RED WIRE RED/BLU WIRE RED/VIO WIRE RIGHT REAR CENTER ARMREST HEATING ELEMENT VIO WIRE VIO/BLK WIRE VIO/GRN WIRE VIO/RED WIRE VIO/YEL WIRE W/ LONG REAR CENTER CONSOLE W/ SHORT REAR CENTER CONSOLE WHT WIRE WIRELESS CONTROL HEAD 1

BLU WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE DRIVER SIDE REAR SEAT TEMPERATURE SENSOR GRN WIRE GRN/BRN WIRE GRY/RED WIRE GRY/VIO WIRE LEFT FRONT CENTER ARMREST HEATING ELEMENT LEFT REAR BACKREST HEATING ELEMENT LEFT REAR BENCH SEAT HEATING ELEMENT LEFT REAR SEAT BACKREST TEMPERATURE SENSOR LEFT REAR SEAT COUPLING POINT PASSENGER SIDE REAR SEAT TEMPERATURE SENSOR RED WIRE RIGHT FRONT CENTER ARMREST HEATING ELEMENT RIGHT REAR BACKREST HEATING ELEMENT RIGHT REAR BENCH SEAT HEATING ELEMENT RIGHT REAR SEAT BACKREST TEMPERATURE SENSOR RIGHT REAR SEAT COUPLING POINT RIGHT REAR SEAT COUPLING STATION VIO/GRN WIRE VIO/RED WIRE VIO/YEL WIRE WHT WIRE
