Audi A8 D5 (2017-2022) w/ access/start authorization system w/o access/start authorization system Wiring diagram

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE FUEL FILLER DOOR LOCK MOTOR GRN WIRE GRN/BLU WIRE GRN/RED WIRE LEFT REAR BUMPER COUPLING POINT LOCK PAWL CONTACT SWITCH LUGGAGE COMPARTMENT REAR LID LOCK BUTTON NCA WIRE ORG/BRN WIRE POWER REAR LID OPENING CONTROL MODULE POWER REAR LID OPENING SENSOR POWER REAR LID OPENING SENSOR 2 REAR LID CENTRAL LOCKING SYSTEM MOTOR REAR LID CONTACT SWITCH REAR LID CONTROL HEAD REAR LID HANDLE RELEASE BUTTON REAR LID LOCK UNIT REAR LID LOCKING MECHANISM BUTTON REAR LID REMOTE RELEASE BUTTON RED/GRN WIRE RED/YEL WIRE W/ ACCESS/START AUTHORIZATION SYSTEM W/O ACCESS/START AUTHORIZATION SYSTEM W/ REAR LID CLOSING AID W/O REAR LID CLOSING AID WHT WIRE YEL WIRE
