Audi A8 D5 (2017-2022) transverse selector lever lock motor Wiring diagrams
This page contains all the electrical diagrams for the component. transverse selector lever lock motor, in which he is found in the car Audi A8 D5 (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram transverse selector lever lock motor (1 of 2)
4-PIN CONNECTOR IN THE STEERING WHEEL
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CENTER COUPLING POINT IN INTERIOR
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
D/S
ENGINE/MOTOR CONTROL MODULE
GRN/WHT WIRE
GRY WIRE
NCA WIRE
ORG/BRN WIRE
PARKING LOCK BUTTON
PARKING LOCK INDICATOR LAMP
RED WIRE
SELECTOR LEVER
SELECTOR LEVER POSITION SENSOR
SELECTOR LEVER RELEASE BUTTON
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE DISPLAY
SHIFT LOCK SOLENOID
STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
TIPTRONIC UPSHIFT BUTTON
TRANSVERSE SELECTOR LEVER LOCK MOTOR
TRANSVERSE SELECTOR LEVER LOCK SENSOR
VIO WIRE
Go to component -> A/t circuit (2 of 2) -> TRANSVERSE SELECTOR LEVER LOCK MOTOR
Wiring diagram transverse selector lever lock motor (2 of 2)
ABS CONTROL MODULE
BLK/BLU WIRE
BLU WIRE
BRAKE LAMP SWITCH
BRAKE PEDAL POSITION SENSOR
BRN WIRE
CENTER COUPLING POINT IN INTERIOR
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
D/S
ENGINE/MOTOR CONTROL MODULE
FUSE 5
FUSE 9
FUSE PANEL A
FUSE PANEL M
GRN WIRE
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER CONTROL MODULE
NCA WIRE
ORG/BRN WIRE
PARKING LOCK BUTTON
PARKING LOCK IND LAMP
PNK WIRE
RED WIRE
SELECTOR LEVER
SELECTOR LEVER POSITION SENSOR
SELECTOR LEVER RELEASE BUTTON
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE DISPLAY
SHIFT LOCK SOLENOID
SYSTEM
TRANSMISSION CONTROL MODULE
TRANSVERSE SELECTOR LEVER LOCK MOTOR
TRANSVERSE SELECTOR LEVER LOCK SENSOR
VIO/RED WIRE
VIO/WHT WIRE
Go to component -> Shift interlock circuit -> TRANSVERSE SELECTOR LEVER LOCK MOTOR
