Audi A8 D5 (2017-2022) satellite tuner antenna Wiring diagrams

This page contains all the electrical diagrams for the component. satellite tuner antenna, in which he is found in the car Audi A8 D5 (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

satellite tuner antenna wiring diagram (1 of 8)

Audi A8 D5 (2017-2022) satellite tuner antenna wiring diagram (1 of 8)

ANTENNA AMPLIFIER 2 (LEFT "D" PILLAR) BLK WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA EMERGENCY CALL MODULE ANTENNA 2 GPS ANTENNA INFORMATION ELECTRONICS CONTROL MODULE 1 (BEHIND RIGHT SIDE OF DASH) LEFT "C" PILLAR) LTE ANTENNA 1 NCA WIRE ORG/BRN WIRE RADIO ANTENNA 2 RED WIRE RED/BLK WIRE ROOF ANTENNA ROOF ANTENNA CONTROL MODULE SATELLITE TUNER ANTENNA VIO WIRE W/ DIGITAL RADIO W/O CONNECT PLUS W/ EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL W/O CONNECT PLUS, EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL

Go to component -> Navigation circuit, w/ amplifier & active noise (4 of 6) -> SATELLITE TUNER ANTENNA

satellite tuner antenna wiring diagram (2 of 8)

Audi A8 D5 (2017-2022) satellite tuner antenna wiring diagram (2 of 8)

ANTENNA AMPLIFIER 2 (LEFT "D" PILLAR) BLK WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA GPS ANTENNA GRN WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 (BEHIND RIGHT SIDE OF DASH) LEFT "C" PILLAR) NCA WIRE ORG/BRN WIRE RADIO ANTENNA 2 RED WIRE RED/BLK WIRE ROOF ANTENNA CONTROL MODULE SATELLITE TUNER ANTENNA VIO WIRE W/O CONNECT PLUS W/ EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL W/O CONNECT PLUS, EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL

Go to component -> Navigation circuit, w/ amplifier & w/o active noise & bang & olufsen sound (4 of 6) -> SATELLITE TUNER ANTENNA

satellite tuner antenna wiring diagram (3 of 8)

Audi A8 D5 (2017-2022) satellite tuner antenna wiring diagram (3 of 8)

ANTENNA AMPLIFIER 2 (LEFT "D" PILLAR) BLK WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA EMERGENCY CALL MODULE ANTENNA 2 GPS ANTENNA INFORMATION ELECTRONICS CONTROL MODULE 1 (BEHIND RIGHT SIDE OF DASH) LEFT "C" PILLAR) LTE ANTENNA 1 NCA WIRE ORG/BRN WIRE RADIO ANTENNA 2 RED WIRE RED/BLK WIRE ROOF ANTENNA CONTROL MODULE SATELLITE TUNER ANTENNA VIO WIRE W/O CONNECT PLUS W/ EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL W/O CONNECT PLUS, EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL

Go to component -> Navigation circuit, w/ amplifier w/o active noise w/ bang & olufsen sound (5 of 7) -> SATELLITE TUNER ANTENNA

satellite tuner antenna wiring diagram (4 of 8)

Audi A8 D5 (2017-2022) satellite tuner antenna wiring diagram (4 of 8)

ANTENNA AMPLIFIER 2 (LEFT "D" PILLAR) BLK WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA EMERGENCY CALL MODULE ANTENNA 2 GPS ANTENNA INFORMATION ELECTRONICS CONTROL MODULE 1 (BEHIND RIGHT SIDE OF DASH) LEFT "C" PILLAR) LTE ANTENNA 1 NCA WIRE ORG/BRN WIRE RADIO ANTENNA 2 RED/BLK WIRE ROOF ANTENNA CONTROL MODULE SATELLITE TUNER ANTENNA VIO WIRE W/ DIGITAL RADIO W/O CONNECT PLUS W/ EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL W/O CONNECT PLUS, EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL

Go to component -> Navigation circuit, w/o amplifier (4 of 6) -> SATELLITE TUNER ANTENNA

satellite tuner antenna wiring diagram (5 of 8)

Audi A8 D5 (2017-2022) satellite tuner antenna wiring diagram (5 of 8)

ANTENNA AMPLIFIER 2 (LEFT "D" PILLAR) BLK WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA EMERGENCY CALL MODULE ANTENNA 2 GPS ANTENNA INFORMATION ELECTRONICS CONTROL MODULE 1 (BEHIND RIGHT SIDE OF DASH) LEFT "C" PILLAR) LTE ANTENNA 1 NCA WIRE ORG/BRN WIRE RADIO ANTENNA 2 RED WIRE RED/BLK WIRE ROOF ANTENNA ROOF ANTENNA CONTROL MODULE SATELLITE TUNER ANTENNA VIO WIRE W/ DIGITAL RADIO W/O CONNECT PLUS W/ EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL W/O CONNECT PLUS, EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL

Go to component -> Radio circuit, w/ amplifier & active noise (4 of 6) -> SATELLITE TUNER ANTENNA

satellite tuner antenna wiring diagram (6 of 8)

Audi A8 D5 (2017-2022) satellite tuner antenna wiring diagram (6 of 8)

ANTENNA AMPLIFIER 2 (LEFT "D" PILLAR) BLK WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA GPS ANTENNA GRN WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 (BEHIND RIGHT SIDE OF DASH) LEFT "C" PILLAR) NCA WIRE ORG/BRN WIRE RADIO ANTENNA 2 RED WIRE RED/BLK WIRE ROOF ANTENNA CONTROL MODULE SATELLITE TUNER ANTENNA VIO WIRE W/O CONNECT PLUS W/ EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL W/O CONNECT PLUS, EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL

Go to component -> Radio circuit, w/ amplifier & w/o active noise & bang & olufsen sound (4 of 6) -> SATELLITE TUNER ANTENNA

satellite tuner antenna wiring diagram (7 of 8)

Audi A8 D5 (2017-2022) satellite tuner antenna wiring diagram (7 of 8)

ANTENNA AMPLIFIER 2 (LEFT "D" PILLAR) BLK WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA EMERGENCY CALL MODULE ANTENNA 2 GPS ANTENNA INFORMATION ELECTRONICS CONTROL MODULE 1 (BEHIND RIGHT SIDE OF DASH) LEFT "C" PILLAR) LTE ANTENNA 1 NCA WIRE ORG/BRN WIRE RADIO ANTENNA 2 RED WIRE RED/BLK WIRE ROOF ANTENNA CONTROL MODULE SATELLITE TUNER ANTENNA VIO WIRE W/O CONNECT PLUS W/ EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL W/O CONNECT PLUS, EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL

Go to component -> Radio circuit, w/ amplifier w/o active noise w/ bang & olufsen sound (5 of 7) -> SATELLITE TUNER ANTENNA

satellite tuner antenna wiring diagram (8 of 8)

Audi A8 D5 (2017-2022) satellite tuner antenna wiring diagram (8 of 8)

ANTENNA AMPLIFIER 2 (LEFT "D" PILLAR) BLK WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA EMERGENCY CALL MODULE ANTENNA 2 GPS ANTENNA INFORMATION ELECTRONICS CONTROL MODULE 1 (BEHIND RIGHT SIDE OF DASH) LEFT "C" PILLAR) LTE ANTENNA 1 NCA WIRE ORG/BRN WIRE RADIO ANTENNA 2 RED/BLK WIRE ROOF ANTENNA CONTROL MODULE SATELLITE TUNER ANTENNA VIO WIRE W/ DIGITAL RADIO W/O CONNECT PLUS W/ EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL W/O CONNECT PLUS, EMERGENCY CALL SERVICE/ ROADSIDE ASSISTANCE CALL

Go to component -> Radio circuit, w/o amplifier (4 of 6) -> SATELLITE TUNER ANTENNA
