Audi A8 D5 (2017-2022) passenger side rear seat sensor temperature Wiring diagram
This page shows the only wiring diagram for the component.passenger side rear seat sensor temperature, which is found in the car Audi A8 D5 (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side rear seat sensor temperature (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DRIVER SIDE REAR SEAT TEMPERATURE SENSOR
GRN WIRE
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR BENCH SEAT HEATING ELEMENT
LEFT REAR SEAT BACKREST BOLSTER HEATING ELEMENT
LEFT REAR SEAT BACKREST TEMPERATURE SENSOR
LEFT REAR SEAT BOLSTER HEATER
LEFT REAR SEAT COUPLING POINT
PASSENGER SIDE REAR SEAT SENSOR TEMPERATURE
RED WIRE
RIGHT REAR BACKREST HEATING ELEMENT
RIGHT REAR BENCH SEAT HEATING ELEMENT
RIGHT REAR SEAT BACKREST BOLSTER HEATING ELEMENT
RIGHT REAR SEAT BACKREST TEMPERATURE SENSOR
RIGHT REAR SEAT BOLSTER HEATER
RIGHT REAR SEAT COUPLING POINT
RIGHT REAR SEAT COUPLING STATION
VIO/GRY WIRE
VIO/RED WIRE
W/O VENTILATION
WHT WIRE
