Audi A8 D5 (2017-2022) parking brake indicator lamp Wiring diagram
This page shows the only wiring diagram for the component.parking brake indicator lamp, which is found in the car Audi A8 D5 (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram parking brake indicator lamp (1 of 1)
ASR/ESP BUTTON
BLK/BLU WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
CENTER COUPLING POINT IN INTERIOR
CENTER SWITCH MODULE IN INSTRUMENT PANEL
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVING, CONVENIENCE FUNCTIONS CONTROL UNIT 1
FUSE 11
FUSE 12
FUSE 9
FUSE PANEL F
GRN/RED WIRE
GRN/VIO WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
NAVIGATION SYSTEM
ORG/BRN WIRE
PARKING BRAKE INDICATOR LAMP
POWER DISTRIBUTION SYSTEM
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
VACUUM SENSOR (NEAR BRAKE BOOSTER)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/BLK WIRE
VIO/WHT WIRE
WHT WIRE
YEL/BLU WIRE
Go to component -> Anti-lock brakes circuit (2 of 3) -> PARKING BRAKE INDICATOR LAMP
