Audi A8 D5 (2017-2022) left front tire pressure monitoring sensor, antenna Wiring diagram
This page shows the only wiring diagram for the component.left front tire pressure monitoring sensor, antenna, which is found in the car Audi A8 D5 (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front tire pressure monitoring sensor, antenna (1 of 1)
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 6
FUSE PANEL M
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
LEFT "C" PILLAR)
LEFT FRONT TIRE PRESSURE MONITORING SENSOR, ANTENNA
LEFT REAR TIRE PRESSURE MONITORING SENSOR, ANTENNA
ORG/BRN WIRE
RED/YEL WIRE
RIGHT FRONT TIRE PRESSURE MONITORING SENSOR, ANTENNA
RIGHT REAR TIRE PRESSURE MONITORING SENSOR, ANTENNA
TIRE PRESSURE MONITORING CONTROL MODULE
Go to component -> Tire pressure monitoring circuit -> LEFT FRONT TIRE PRESSURE MONITORING SENSOR, ANTENNA
