Audi A8 D5 (2017-2022) front pedestrian protection pressure hose sensor Wiring diagram
This page shows the only wiring diagram for the component.front pedestrian protection pressure hose sensor, which is found in the car Audi A8 D5 (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front pedestrian protection pressure hose sensor (1 of 1)
BLK/VIO WIRE
BLK/YEL WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
CENTER PEDESTRIAN PROTECTION CRASH SENSOR
COUPLING POINT ON LEFT FRONT BUMPER
DRIVER SIDE PEDESTRIAN PROTECTION CRASH SENSOR
DRIVER SIDE PEDESTRIAN PROTECTION CRASH SENSOR 2
FRONT PASSENGER SEAT BELT SWITCH
FRONT PASSENGER SEAT HEATING ELEMENT, PASSENGER SEAT OCCUPANT DETECTION SENSOR
FRONT PASSENGER SEAT POSITION SENSOR
FRONT PASSENGER SIDE PEDESTRIAN PROTECTION CRASH SENSOR
FRONT PASSENGER SIDE PEDESTRIAN PROTECTION CRASH SENSOR 2
FRONT PEDESTRIAN PROTECTION PRESSURE HOSE SENSOR
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/YEL WIRE
PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT FRONT SEAT COUPLING STATION
SEAT BELT BUCKLE ASSEMBLY)
VIO WIRE
VIO/GRY WIRE
WHT WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit (2 of 7) -> FRONT PEDESTRIAN PROTECTION PRESSURE HOSE SENSOR
