Audi A8 D5 (2017-2022) engine pre-wiring coupling point 1 Wiring diagrams
This page contains all the electrical diagrams for the component. engine pre-wiring coupling point 1, in which he is found in the car Audi A8 D5 (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram engine pre-wiring coupling point 1 (1 of 5)
AFTER-RUN COOLANT PUMP
BLK WIRE
BLK/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET
ENGINE PRE-WIRING COUPLING POINT 1
ENGINE/ MOTOR CONTROL MODULE
FUSE 13
FUSE PANEL A
GRN/GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
MAP CONTROLLED ENGINE COOLING THERMOSTAT
ORG/BRN WIRE
RADIATOR FAN
RADIATOR FAN 2
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RADIATOR FAN FUSE
RADIATOR FAN SECOND SPEED FUSE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, w/o rear controls & second heating system (6 of 6) -> ENGINE PRE-WIRING COUPLING POINT 1
Wiring diagram engine pre-wiring coupling point 1 (2 of 5)
AFTER-RUN COOLANT PUMP
BLK WIRE
BLK/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET
ENGINE PRE-WIRING COUPLING POINT 1
ENGINE/MOTOR CONTROL MODULE
FUSE 13
FUSE PANEL A
GRN/GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
MAP CONTROLLED ENGINE COOLING THERMOSTAT
ORG/BRN WIRE
RADIATOR FAN
RADIATOR FAN 2
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RADIATOR FAN FUSE
RADIATOR FAN SECOND SPEED FUSE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, w/o rear controls w/ second heating system (6 of 6) -> ENGINE PRE-WIRING COUPLING POINT 1
Wiring diagram engine pre-wiring coupling point 1 (3 of 5)
AFTER-RUN COOLANT PUMP
BLK WIRE
BLK/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET
ENGINE PRE-WIRING COUPLING POINT 1
ENGINE/MOTOR CONTROL MODULE
FUSE 13
FUSE PANEL A
GRN/GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
MAP CONTROLLED ENGINE COOLING THERMOSTAT
ORG/BRN WIRE
RADIATOR FAN
RADIATOR FAN 2
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RADIATOR FAN FUSE
RADIATOR FAN SECOND SPEED FUSE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
WHT/VIO WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, w/ rear controls (6 of 6) -> ENGINE PRE-WIRING COUPLING POINT 1
Wiring diagram engine pre-wiring coupling point 1 (4 of 5)
AFTER-RUN COOLANT PUMP
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
COOLANT RECIRCULATION PUMP
ENGINE COOLANT LEVEL SENSOR
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET
ENGINE PRE-WIRING COUPLING POINT 1
ENGINE/MOTOR CONTROL MODULE
FUSE 13
FUSE 14
FUSE 6
FUSE 8
FUSE PANEL A
GRN WIRE
GRN/GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
MAP CONTROLLED ENGINE COOLING THERMOSTAT
ORG/BRN WIRE
RADIATOR FAN
RADIATOR FAN 2
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RADIATOR FAN FUSE
RADIATOR FAN SECOND SPEED FUSE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT/BRN WIRE
WHT/VIO WIRE
YEL/VIO WIRE
Go to component -> Cooling fan circuit -> ENGINE PRE-WIRING COUPLING POINT 1
Wiring diagram engine pre-wiring coupling point 1 (5 of 5)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
BRN/BLU WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVER ACTIVITY SENSOR
DRIVER ASSISTANCE SYSTEM IND LAMP
DRIVER ASSISTANCE SYSTEMS CONTROL MODULE
ENGINE COOLANT LEVEL SENSOR
ENGINE ELECTRONICS IND LAMP
ENGINE PRE-WIRING COUPLING POINT 1
ENGINE/MOTOR CONTROL MODULE
FUEL DELIVERY UNIT (UNDER RIGHT REAR SEAT)
FUEL DELIVERY UNIT COUPLING POINT
FUEL LEVEL SENSOR
FUEL LEVEL SENSOR 2
FUEL LEVEL SENSOR 4
FUSE 11
FUSE 4
FUSE 9
FUSE PANEL D
FUSE PANEL F
GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INFORMATION ELECTRONICS CONTROL MODULE 1
INSTRUMENT CLUSTER CONTROL MODULE
LEFT TURN SIGNAL IND LAMP
NCA WIRE
NIGHT VISION CIRCUIT
OIL PRESSURE SWITCH
ORG/ WIRE
ORG/BRN WIRE
OUTSIDE AIR TEMPERATURE SENSOR
PARKING BRAKE IND LAMP
PNK WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT EMERGENCY FLASHER IND LAMP
SOUND SYSTEMS
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
WHT/GRY WIRE
WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE
WINDSHIELD WASHER FLUID LEVEL SENSOR
YEL/BLK WIRE
Go to component -> Instrument cluster circuit -> ENGINE PRE-WIRING COUPLING POINT 1
