Audi A8 D5 (2017-2022) electro- mechanical power steering motor Wiring diagram
This page shows the only wiring diagram for the component.electro- mechanical power steering motor, which is found in the car Audi A8 D5 (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electro- mechanical power steering motor (1 of 1)
BATTERY INTERRUPT IGNITER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRO- MECHANICAL POWER STEERING MOTOR
FUSE 1
FUSE 16
FUSE PANEL F
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BRN WIRE
PNK WIRE
POWER STEERING CONTROL MODULE
RED WIRE
STEERING ANGLE SENSOR
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING TORQUE SENSOR
TOP RIGHT COUPLING POINT ON ENGINE
YEL WIRE
Go to component -> Electromechanical power steering circuit -> ELECTRO- MECHANICAL POWER STEERING MOTOR
