Audi A8 D5 (2017-2022) driver multi-contour seat compressor Wiring diagrams
This page contains all the electrical diagrams for the component. driver multi-contour seat compressor, in which he is found in the car Audi A8 D5 (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
driver multi-contour seat compressor wiring diagram (1 of 2)
BLK/BLU WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/YEL WIRE
DRIVER BACKREST ADJUSTMENT MOTOR
DRIVER HEADREST HEIGHT ADJUSTMENT MOTOR
DRIVER MULTI-CONTOUR SEAT COMPRESSOR
DRIVER SEAT ANGLE ADJUSTMENT MOTOR
DRIVER SEAT DEPTH ADJUSTMENT MOTOR
DRIVER SEAT FORWARD/BACK ADJUSTMENT MOTOR
DRIVER SEAT VALVE BLOCK 1
DRIVER SEAT VALVE BLOCK 2
GRY/BRN WIRE
GRY/RED WIRE
HEADREST HEIGHT ADJUSTMENT SENSOR
RED WIRE
RED/BLK WIRE
W/ LUMBAR SUPPORT
W/ LUMBAR SUPPORT ADJUSTMENT, MASSAGE FUNCTION
WHT/VIO WIRE
Go to component -> Driver"s memory seat circuit, w/ comfort seats (2 of 3) -> DRIVER MULTI-CONTOUR SEAT COMPRESSOR
driver multi-contour seat compressor wiring diagram (2 of 2)
BLK/BLU WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/YEL WIRE
DRIVER BACKREST ADJUSTMENT MOTOR
DRIVER HEADREST HEIGHT ADJUSTMENT MOTOR
DRIVER HEADREST HEIGHT ADJUSTMENT SENSOR
DRIVER MULTI-CONTOUR SEAT COMPRESSOR
DRIVER SEAT ANGLE ADJUSTMENT MOTOR
DRIVER SEAT DEPTH ADJUSTMENT MOTOR
DRIVER SEAT FORWARD/BACK ADJUSTMENT MOTOR
DRIVER SEAT VALVE BLOCK 1
DRIVER SEAT VALVE BLOCK 2
GRY/BRN WIRE
GRY/RED WIRE
RED WIRE
RED/BLK WIRE
W/ LUMBAR SUPPORT ADJUSTMENT, MASSAGE FUNCTION
WHT/VIO WIRE
Go to component -> Driver"s memory seat circuit, w/ sport seats (2 of 3) -> DRIVER MULTI-CONTOUR SEAT COMPRESSOR
