Audi A8 D5 (2017-2022) driver headrest adjustment switch Wiring diagram
This page shows the only wiring diagram for the component.driver headrest adjustment switch, which is found in the car Audi A8 D5 (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver headrest adjustment switch (1 of 1)
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER BACKREST ADJUSTMENT SWITCH
DRIVER HEADREST ADJUSTMENT SWITCH
DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
DRIVER SEAT ADJUSTMENT CONTROL HEAD
DRIVER SEAT ANGLE ADJUSTMENT SWITCH
DRIVER SEAT COUPLING POINT
DRIVER SEAT FORWARD/BACK ADJUSTMENT SWITCH
DRIVER SEAT HEIGHT ADJUSTMENT MOTOR
DRIVER SEAT HEIGHT ADJUSTMENT SENSOR
DRIVER SEAT HEIGHT ADJUSTMENT SWITCH
DRIVER SEAT SWITCH MODULE
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
WHT WIRE
WHT/VIO WIRE
Go to component -> Driver"s memory seat circuit, w/ sport seats (1 of 3) -> DRIVER HEADREST ADJUSTMENT SWITCH
